Name: High Accuracy Bimetallic Thermometer For Engineering Measurement Instrument
Brand: NINGBO SANMIN IMPORT AND EXPORT CO.,LTD.
SKU: SMC1S
Price: Negotiable USD
Availability: InStock

Home Products Bimetallic Coil Thermometer

High Accuracy Bimetallic Thermometer For Engineering Measurement Instrument

Product Details:

Place of Origin:	China
Brand Name:	Mkfale
Model Number:	SMC1S

Payment & Shipping Terms:

Minimum Order Quantity:	1PC
Price:	Negotiation
Packaging Details:	Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
Delivery Time:	5 - 30 Work Days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	Negotiation

Contact Now

Detailed Product Description

Nominal Size:	2 1 / 2 " , 3 " , 4 " , 5 " , 6 "	Accuracy Class:	Class 1 . 0
Ingress Protection:	IP 65	Connection Size:	Fixed Connection Or Sliding Connection
Thread:	Size G1 / 4 " ,G1 / 2 " Or NPT	Temperature:	- 50 ° .. + 120 ℃
Highlight:	bimetallic stem thermometer , digital industrial thermometer

High Accuracy Bimetallic Thermometer For Engineering Measurement Instrument

Technical Specification Table

Type		SMC1S High Accuracy Stainless Steel Bimetal thermometer
Application		All stainless steel thermometer.Suitable for corrosive media and environments in chemical process,petroleum and food industry. The instruments meet the highest standards of measurement technique.
Features		Accuracy class 1.0, Quick response and high accuracy External micro adjustment device, All stainless steel material Hermetically sealed case structure, Temperature range up to 600℃(1100°F) Standard dial dual unit ranges(°F & ℃), Sensor length up to 1000mm Sensor diameter 6(standard),6.3,8 or 10mm
Technical Specification	Nominal Size	21/2",3",4",5"and 6"
	Accuracy Class	Class 1.0
	Ingress Protection.	IP65
	Connection Size	Fixed connection or Sliding connection, Size G1/4",G1/2" or NPT
	Temperature Scale Range	-40° ..+600℃(-40° ..+100°F)
	Sensing Element	Coiled bimetal sensing
	Filling	Dry, but Fillable Silicone oil
	Operating Temperature	Ambient temperature -50° ..+120℃
	Bezel Ring Type	Bayonet case sealed, Exlernal calibralion device on back case
	Dial Graduation	Standard in dual ranges °F and ℃
Design Material	Casing and Bezel Ring	SS304
	Probe/bulb Sensor	SS316L
	connection	Stainless steel 304, sliding connection, or * Fixed welded connection
	Window	Plain instrement glass
	Pointer	Black painted aluminium
	Dial Plate	Aluminium alloy, bowl cuppied type

Why choose us

1: Various style for each products and completely series industry instruments.
2: Large stock for fast shipping .
3: High quality with competitive price .
4: Sample order & small quantity order is acceptable .
5: Customize according to your special request .

FAQ

Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .

Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.

Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.

Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .
