Wear Resistant Flange Flow Meter IP68 Protection Class , 0 ~ 15m / S Flow Rate
Technical Specification Table
SMBP Battery Powered Converter with Flange Connection Sensor :
Remote Separate Type
Nominal Diameter :
DN10 ~ DN800
Accuracy :
± 0 . 5
Medium conductivity :
Clean water > 20us / cm
Flow rate :
0 ~ 15m / s
Working temperature :
- 20 ℃ ~ 50 ℃
Operating humidity :
≤ 95 %
Protection class :
IP68
Measurement parameters :
Instantaneous flow , instantaneous flow rate
Record parameters :
Total meters
Detection and alarm parameters :
Fluid empty pipe detection alarm , the excitation current detection alarm
Scaled output signal :
Unit volume flow pulse
Communication :
Rs485 ( modbus protocol ) , GPRS
Battery life ( month )
| Measuring cycle |
3S |
4S |
5S |
6S |
7S |
8S |
9S |
10S |
11S |
12S |
13S |
14S |
15S |
30S |
| 50mA excitation |
12 |
16 |
20 |
24 |
28 |
32 |
36 |
40 |
40 |
48 |
52 |
56 |
60 |
120 |
| 20mA excitation |
19 |
26 |
33 |
39 |
46 |
53 |
59 |
66 |
66 |
79 |
86 |
93 |
100 |
200
|
Why choose us
1: Various style for each products and completely series industry instruments.
2: Provide free products information .
3: Reliable quality assured and active after-sell service
4: Large stock for fast shipping .
5: High quality with competitive price .
FAQ
Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .
Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.
Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .
Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
